SERVICING AND INSPECTION
159
WL50
Item Point of lubrication Nipples
13 Bearing for reversing lever [1]
14 Tie rod, front [1]
15 Cab tipping cylinder (under the cab) [2]
16 Drive shaft, rear [1]
17 Center pivot bearing, top (remote lubrication) [1]
18 Steering cylinder, rear (remote lubrication) [1]
19 Center pivot lager, bottom [1]
20 Steering cylinder, front [1]
21 Drive shaft, front [1]
22 Tie rod, rear [1]
23 Pivot point of tool attachment [2]
24 Tool locking bolts [2]
Item Point of lubrication Nipples
1 Engine enclosure hinges [2]
2 Cab tilting hinge, rear [1]
3 Door hinges [4]
4 Brake pedal bearing (in the cab) [1]
Brake lever bearing (under the cab) [1]
5 Accelerator (in the cab) [1]
6 Cab tilting hinge, front [1]
7 Center pivot bearing, top [1]
8 Lifting cylinder, rear [2]
9 Arm, top [2]
10 Tipping cylinder, rear [1]
11 Lifting cylinder, front [2]
12 Tipping cylinder, front [1]
Lubricate all the points of lubrication daily with water-resistant multi-purpose grease. Lubricate all other moving parts
such as the handbrake lever, foot pedals, cables, etc. using the oil can.
