TECHNICAL DATA
45
WL50
*In the event of deviating tires or reversed wheel rims the dimensions will change
Dimensions with 405/70 R18 EM tires
Item Designation Value
A Overall length with standard
shovel
5417 mm 213.3 inch
A‘ Overall length without shovel 4545 mm 178.9 inch
B Axle center to shovel pivot-
point
1030 mm 40.6 inch
C Wheelbase 2005 mm 78.9 inch
D Rear overhang 1445 mm 56.9 inch
E Overhead loading height* 3094 mm 121.8 inch
F Max. height of shovel pivot
point*
3336 mm 131.3 inch
G Height of seat* 1563 mm 61.5 inch
H Max. dumping height* 2569 mm 101.1 inch
I Scraping depth* 50 mm 1.97 inch
K Reach at H* 723 mm 28.5 inch
L Height to top of cab* 2602 mm 102.4 inch
Item Designation Value
M Total working height* 4090 mm 161.0 inch
N Max. dumping angle at max.
lift height
38°
O Reverse roll angle on ground 43°
P Reverse roll angle at max. lift 45°
Q Inside turning radius* 1546 mm 60.9 inch
R Overall width* 1840 mm 72.4 inch
S Radius at outer edge* 3449 mm 135.8 inch
T Ground clearance* 377 mm 14.8 inch
U Turn angle 44°
V Width across cab 1251 mm 49.3 inch
W Track width* 1400 mm 55.1 inch
Z Maximum turning radius
(depends on shovel width)
3908 mm 153.9 inch
