DesCRIpTION Of The INDICATOR, WARNING AND CONTROl elemeNTs
49
WL50
Item Designation Function Symbol
1 Heater indicator light Illuminates during preheating
2
Indicator light for electrical connection on loader lift
arms (optional equipment)
Illuminates when electrical connection is switched on.
3 Warning light for return lter Illuminates if the pressure at the return lter is too high
4 No function Available for optional equipment
1
5 Indicator for fuel display
Illuminates when the fuel quantity falls to approx. 5 l (1.6
gallons)
*6
Warning light for engine temperature / hydraulic oil
temperature
Illuminates when engine temperature / hydraulic oil
temperature is too high
7 Warning light for alternator
Is illuminated if the battery is not accepting an electrical
charge
8 Indicator light for turn signal Illuminates when a turn signal is on
