OPERATING AND OPERATION
67
WL50
Lengthwise adjustment of the seat separately 3.
from the steering console:
Adjust the seat in the lengthwise direction by pushing the
locking lever upwards. After the adjustment, the locking
lever must click into place in the desired position. The op-
erator’s seat should not move again after it has been locked
in place.
Lengthwise adjustment of the seat together
4.
with the steering console:
Adjust the seat in the lengthwise direction, together with
the steering console, by pushing the locking bar upwards.
After the adjustment, the locking bar must click into place in
the desired position. The operator’s seat should not move
again after it has been locked in place.
Weight adjustment:5.
Adjust the weight while sitting in the seat, by turning the
weight adjustment knob. The viewing window Fig. 26 (mag-
nication) allows you to read off the weight set.
Backrest adjustment:6.
Use the locking lever to adjust the degree of tilt of the back-
rest. The locking lever should lock in the desired position.
The backrest should not move again after it has been locked
in place.
