WAGO 750 XTR User Manual

26 Device Description WAGO I/O System 750 XTR
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
3.5 Technical Data
3.5.1 Device Data
Table 7: Technical Data – Device
Width
12 mm
Depth (from upper edge of DIN-rail)
60.6 mm
Height
100 mm
Weight
38 g
Degree of protection
IP20
3.5.2 Power Supply
Table 8: Technical Data – Power Supply
Current consumption,
system voltage
max.
85 mA
Current consumption, power jumper
contact
typ.
(24 VDC) 20 mA without load
Voltage supply via power jumper
contacts
under laboratory conditions
for ambient operating temperature
−40 °C … +55 °C
for ambient operating temperature
+55 °C … +70 °C
24 VDC (power supply via SELV/PELV
power supply unit)
18 V … 31,2 V (17,4 V … 31,2 V)
*)
18 V … 28,8 V (17,4 V … 28,8 V)
*)
18 V … 26,4 V (17,4 V … 26,4 V)
*)
Current
max.
via power jumper contacts
.
10 A
Rated surge voltage
1 kV
*)
Including residual ripple of 15 %
