WAGO 750 XTR User Manual

WAGO I/O System 750 XTR Device Description 27
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
Table 9: Technical Data − Outputs
Number of outputs
4 (Push-Pull)
Output current per channel
0.2 A short-circuit-protected;
0.4 A short-circuit-protected in bridge
mode
Switching frequency (max.)
20 kHz
PWM pulse duty factor
0 … 100 %; 11-bit resolution
PWM frequency
0 … 20,000 Hz; integer
Operating modes
*)
1: PWM DC (variable duty cycle);
2: PWM Frq (variable frequency);
3: PWM Frq-Cnt;
4: Pulse Frq-Cnt;
5: PWM Pulse-Dir
Diagnostics
• Per module: Undervoltage;
• Per channel pair of a bridge:
Short circuit after Uout+ or Uout–
Data width
4 × 16-bit data;
4 × 8-bit control/status
Supply voltage (field)
24 VDC (−25 … +30 %);
via power jumper contacts
(power supply via blade contact;
transmission via spring contact)
Derating (supply voltage)
Surrounding air temperature under
laboratory conditions: (−25 … +30 %);
For −40 … +55 °C: 24 V (−25 … +20 %);
For +55 … +70 °C: 24 V (−25 … +10 %);
Lower limit in all temperature ranges:
−27.5 % (including 15 % residual ripple)
Supply voltage (system)
5 VDC; via data contacts
Power consumption
(5 V system supply)
.
85 mA
Power consumption, field supply
(module with no external load)
20 mA
isolation
500 V system/field
Current carrying capacity
(power jumper contacts)
10 A
Number of incoming power jumper
contacts
2
Number of outgoing power jumper
contacts
2
*)
