Page #77 background image
WAGO I/O System 750 XTR Commissioning 77
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
Table 57: 750-677, “Channel X & Y” Menu Item
Parameter
Setting Option / Description
Bridge mode
1), 2)
Synchronization of the two channels, which enables
parallel connection to double the output current.
Bridge mode enabled, i.e., both
channels work synchronously.
The settings from the first
channel are adopted for both.
*)
Both channels can be configured
differently.
OP-Mode
Selection of the operating mode for the channel or the
channel pair
PWM DC
*)
Variable duty cycle;
Frequency can be preset
PWM Frq
Variable frequency;
Duty cycle can be preset
PWM Frq-Cnt
**)
Variable frequency, counter;
Duty cycle can be preset
Pulse Frq-Cnt
**)
Variable frequency, counter;
Pulse duration can be preset
PWM Pulse-Dir
**)
Variable number of pulses,
counter;
Frequency and duty cycle can be
preset
Frequency
1), 5)
1 … 250
*)
… 20000 Hz
Preset frequency in the range of
values 120,000 Hz
Duty cycle
2), 3), 5)
0 … 50
*)
… 100 %
Preset duty cycle in the range of
values 0100 %
Pulse duration
4)
1 … 50
*)
1000000 μs
Preset pulse duration in the
range of values 11,000,000
μs
