WAGO I/O System 750 XTR Operating Modes 57
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
Maximum value of the parameter preset depends on the frequency and duty
cycle
The pulse duration preset is only taken into account up to the value which,
depending on the frequency set, leads to a duty cycle of max. 100 %.
4.4.3 Function of the Output Channels
Output 1 (DO 1): Output signal
Output 2 (DO 2): Count direction
*)
Output 3 (DO 3): Output signal
Output 4 (DO 4): Count direction
*)
*)
L = negative: −1 … −20,000 Hz or 0xB1E0 to 0xFFFF,
H = positive: 1 … 20,000 Hz or 0x0001 to 0x4E20
4.4.4 Process Values (Pulse Frq-Cnt)
The frequency is specified in [Hz] via the process output data.
1 digit equals 1 Hz.
Valid value ranges for the process image:
• Positive value range: 0x0001 … 0x4E20 (1 Hz … 20000 Hz)
• Negative value range: 0xB1E0 … 0xFFFF (
−20000 Hz … −1 Hz)
Table 46: Process Values (Pulse Frq-Cnt)
Frequency
[Hz]
Numeric Value
Output
DO 2 or DO 4
Binary
Hex.
Dec.
20000
'0100.1110.0010.0000'
0x4E20
20000
High
15000
'0011.1010.1001.1000'
0x3A98
15000
High
10000
'0010.0111.0001.0000'
0x2710
10000
High
5000
'0001.0011.1000.1000'
0x1388
5000
High
1
'0000.0000.0000.0001'
0x0001
1
High
0
'0000.0000.0000.0000'
0x0000
0
Low oder High
*)
−1
'1111.1111.1111.1111'
0xFFFF
65535
Low
−5000
'1110.1100.0111.1000'
0xEC78
60536
Low
−10000
'1101.1000.1111.0000'
0xD8F0
55536
Low
−15000
'1100.0101.0110.1000'
0xC568
50536
Low
−20000
'1011.0001.1110.0000'
0xB1E0
45536
Low
*)
If the process value = 0, the previous level of the direction output is retained.
