46 Operating Modes WAGO I/O System 750 XTR
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
Output 3 (DO 3): Output signal 3
Output 4 (DO 4): Output signal 4
4.1.4 Process Values
The pulse-pause ratio is specified in [%] via the process output data.
A duty cycle of 100 % corresponds to the value 2048.
Valid value range for the process image: 0 … 2048
The process value is calculated based on the following formula:
 = 2048 ∗ 
[
%
]
100
Table 28: Process Values (PWM DC)
Duty cycle [%]
Numeric Value
Binary
Hex.
Dec.
100.00
'0000.1000.0000.0000'
0x0800
2048
75.00
'0000.0110.0000.0000'
0x0600
1536
50.00
'0000.0100.0000.0000'
0x0400
1024
25.00
'0000.0010.0000.0000'
0x0200
512
0.00
'0000.0000.0000.0000'
0x0000
0
