56 Operating Modes WAGO I/O System 750 XTR
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
Table 44: Status Byte 0 (Pulse Frq-Cnt)
Status byte 0
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Reg
Com
General Error
Bit
Undervoltage
Short circuit
DO 1 or
DO 2
Status of
output
DO 2
-
PWM
enabled
Enable DO 1
&
DO 2 Drivers
Legend
RegCom
0: Register communication is disabled (normal mode).
1: Register communication is enabled.
Table 45: Status Byte 2 (Pulse Frq-Cnt)
Status byte 2
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Reg
Com
General Error
Bit
Undervoltage
Short circuit
DO 3 or
DO 4
Status of
output
DO 4
-
PWM
enabled
Enable DO 3
&
DO 4 Drivers
Legend
Enable DO 3 & DO 4
Drivers
0: The status of the output driver for DO 3 & DO 4 is disabled.
1: The status of the output driver for DO 3 & DO 4 is enabled.
PWM enabled
0: No output of a PWM signal is enabled.
1: The PWM output is enabled.
Status of output DO 4
0: The output DO 4 is disabled.
1: The output DO 4 is enabled.
Short circuit DO 3 or
DO 4
0: There is no short circuit at outputs DO 3 or DO 4.
1: There is a short circuit at output DO 3 or DO 4.
Undervoltage
0: There is no undervoltage on the I/O module.
1: There is an undervoltage on the I/O module.
General Error Bit
0: There is no error.
1: There is an undervoltage or a short circuit.
Bits 0-3 are masked out.
RegCom
0: Register communication is disabled (normal mode).
1: Register communication is enabled.
Status byte 1 and 3 are permanently “0”.
Frequency Level Depends on Duty Cycle
The frequency preset can only be taken into account to the extent that leads to a
duty cycle of max. 100%.
4.4.2 Parameter Settings
The pulse duration can be preset in the range from 1 … 1,000,000 µs.
The set value is non-volatile and is retained after a restart.
