WAGO I/O System 750 XTR Operating Modes 49
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
4.2.2 Parameter Settings
The duty cycle can be preset in a range of 0 100 %.
When switching on for the first time, the default value of 50 % is loaded for this
parameter.
4.2.3 Function of the Output Channels
Output 1 (DO 1): Output signal 1
Output 2 (DO 2): Output signal 2
Output 3 (DO 3): Output signal 3
Output 4 (DO 4): Output signal 4
4.2.4 Process Values
The frequency is specified in [Hz] via the process output data.
1 digit equals 1 Hz.
Valid value range for the process image: 0 … 20000
Table 34: Process Values (PWM Frq)
Frequency [Hz]
Numeric Value
Binary
Hex.
Dec.
20000
'0100.1110.0010.0000'
0x4E20
20000
15000
'0011.1010.1001.1000'
0x3A98
15000
10000
'0010.0111.0001.0000'
0x2710
10000
5000
'0001.0011.1000.1000'
0x1388
5000
1
'0000.0000.0000.0001'
0x0001
1
0
'0000.0000.0000.0000'
0x0000
0
