WAGO I/O System 750 XTR Device Description 37
750-677/040-000 4PWM 24 VDC 0.2A XTR
Manual
Version 1.0.0
Table 19: EMc – Testing Standards: Emission of Interference
Standard
Test Value
*)
Conducted Emissions – Wired Network Ports
• EN 55032 Class A
53 dB(μA) … 43 dB(μA) QP,
0.15 MHz ... 0.5 MHz
40 dB(μA) … 30 dB(μA) AV,
0.15 MHz ... 0.5 MHz
43 dB(μA) QP, 0.5 MHz ... 30 MHz
30 dB(μA) AV, 0.5 MHz ... 30 MHz
• EN 55032 Class B
40 dB(μA) … 30 dB(μA) QP,
0.15 MHz ... 0.5 MHz
30 dB(μA) … 20 dB(μA) AV,
0.15 MHz ... 0.5 MHz
30 dB(μA) QP, 0.5 MHz ... 30 MHz
20 dB(μA) AV, 0.5 MHz ... 30 MHz
*)
QP = Quasi Peak Detector; AV = Average Detector
**)
If necessary, please find different data in the section “Approval” (regarding approval for EMC A or
EMC B).
