B-2 Specifications
Altitude 2000 m (6561.6 feet)
Line frequency 50/60 Hz
Fuse ratings Two fuses: 100 to 240 VAC, 50 to 60
Hz
F 3.15 A, 250 V FAST BLO, 5 × 20
mm (IEC)
Power consumption 280 VA (nominal)
Two attenuated analog output
channels: 1 VFS
Attenuation range: 1 to 100,000
EUFS
1V output range: –0.1 to +1.1 V
Two event outputs Type: Contact closure
Voltage: +30 V
Current: 1 A
Four event inputs Input voltage: +30 V maximum
100 ms (minimum period)
a. Protection Class I – The insulating scheme used in the instrument to protect from elec-
trical shock. Class I identifies a single level of insulation between live parts (wires) and
exposed conductive parts (metal panels), in which the exposed conductive parts are con-
nected to a grounding system. In turn, this grounding system is connected to the third pin
(ground pin) on the electrical power cord plug.
b. Overvoltage Category II
– Pertains to instruments that receive their electrical power
from a local level such as an electrical wall outlet.
c. Pollution Degree 2
– A measure of pollution on electrical circuits, which may produce a
reduction of dielectric strength or surface resistivity. Degree 2 refers only to normally
nonconductive pollution. Occasionally, however, expect a temporary conductivity caused
by condensation.
d. Moisture Protection – Normal (IPXO) – IPXO means that no Ingress Protection
against any type of dripping or sprayed water exists. The X is a placeholder that identi-
fies protection against dust, if applicable.
Performance specifications
Attribute Specification
Wavelength range Ex: 200 to 890 nm
Em: 210 to 900 nm
Bandwidth 20 nm (maximum)
Wavelength accuracy +
3 nm
Electrical specifications (Continued)
Attribute Specification
