Making signal connections 2-7
Connecting the Ethernet cable
The Waters instrument communicates with the acquisition computer through
the dedicated local area network (LAN). At the acquisition computer, the
instrument network card provides the communications interface.
You must install the instrument control software driver (ICS) in the
acquisition computer so that the computer can control the instrument.
(Consult the software installation instructions that accompany the
instrument control software for details.)
Single Waters instrument connection
In a single Waters instrument system configuration, the connection hardware
requires only one CAT 5, shielded, Ethernet cross-over cable (startup kit).
Event inputs • System controller (used with the
Waters Alliance
®
Separations
Module and the 600-series
solvent delivery system)
• Waters 700 Series or a
non-Waters autosampler
• Waters or other manual injector
RS-232 Allows remote control and direct
data acquisition from an Empower
system or a Millennium
32
workstation (version 3.2 and later)
in 474 emulation mode.
Component connector types (Continued)
Connector type Component
