2-36 Setting Up the Detector
Connecting to the electricity source
The 2475 detector requires a separate, grounded electricity source. The
ground connection in the electrical outlet must be common and connected near
the system.
To connect to the electricity source:
Tip: Use a line conditioner or an uninterruptible power supply (UPS) for
optimum long-term input voltage stability.
1. Place the Off/On ( ) switch in the Off ( ) position.
2. Connect the female end of the power cord to the receptacle on the rear
panel of the detector.
3. Connect the male end of the power cord to a suitable wall outlet.
Tip: Do not turn the detector on at this time.
Warning: To avoid electrical shock:
• Use power cord SVT-type in the United States and HAR-type or
better in Europe. For other countries, contact your local Waters
distributor.
• Power-off and unplug the detector before performing any
maintenance operation on the instrument.
• Connect the detector to a common ground.
