Setting Up the 600 as a PowerLine Controller 53
The Function parameter on the Pump Configuration screen (Figure 4-7) identifies the
module connected to the RS-232 interface. This module can be either the:
• 745B Data Module
• 746 Data Module
Table 4-1 lists the default RS-232 communication parameter values defined by the
controller.
Selecting an Integrator on the RS-232 Connector
1. Move the cursor to the Function field on the Pump Configuration screen (see
Figure 4-7).
2. Type the number for the module you want to use:
• 0 for no device connected
• 1 for a Waters 745B Data Module
• 2 for a Waters 746 Data Module
3. Press Enter. The system automatically displays the default RS-232 communication
parameters in the fields at the bottom of the screen.
4. If you want to select or change the report type, continue with Section 4.1.3,
Selecting the Report Type.
Table 4-1 Default RS-232 Communication Parameter Values
Parameter
Function=0
(Host Link)
Function=1
(745B)
Function=2
(746)
Baud Rate 9600 1200 1200
Bit Number 8 8 8
Stop bits number 1 1 1
Handshake CTS/RTS CTS XON/XOFF
Parity: Enabled
Even/Odd
No Even No Even No Even
STOP
Attention: Do not change the default RS-232 communication parameters at the
bottom of the screen. Otherwise, communication problems will result.
