Maintenance
214 Xerox
®
AltaLink
®
C80XX Series Multifunction Printer
User Guide
Drum Cartridges
Replacing the Drum Cartridges
A message appears on the control panel when a drum cartridge must be replaced.
Note: Each drum cartridge includes installation instructions.
To replace a drum cartridge:
C
AUTION: Do not perform this procedure when the printer is copying or printing.
C
AUTION: Do not expose the drum cartridge to direct sunlight or strong indoor
fluorescent lighting. Do not touch or scratch the surface of the drum.
1. Open the front cover of the printer.
2. T
urn the belt tension lever to the left.
3. P
ull the drum cartridge cover down until it clicks into the open position.
