Clearing Jams at Door D
1. Remove paper from the left tray, then close the tray.
2. To open Door A, open Tray 5, lift the release lever, then open Door A.
WA
RNING: The area around the fuser can be hot. Use caution to avoid injury.
C
AUTION: Do not touch the transfer belt. Touching the belt can reduce image quality or
damage the transfer belt. Do not touch the transfer roller. Touching the roller can reduce
image quality.
3
1
2
