Getting Started
Xerox
®
AltaLink
®
C80XX Series Multifunction Printer 29
User Guide
Rear View
1. Circuit Breaker
2. Rear Right Cover
3. USB Memory Card Connections and SIM Slot
4. USB Port, Type A
5. USB Port, Type B
6. Status Indicator
7. Side 2 Scan Cable
8. Data Port, for service only
9. Ethernet Connection
10. Foreign Device Interface (optional)
11. Fax Connections (optional)
12. Door D Release Lever
13. Door A Release Lever
14. Door B Release Lever
15. Door C Release Lever
Note: Ensure that the rear right cover is attached. To connect an interface cable, open this cover.
13
14
15
3
4
5
6
7
2
1
8
9
10
11
12
