Xerox AltaLink C80 Series - Second Bias Transfer Roller

Maintenance
220 Xerox
®
AltaLink
®
C80XX Series Multifunction Printer
User Guide
Second Bias Transfer Roller
Replacing the Second Bias Transfer Roller
When the second bias transfer roller needs to be replaced, a message appears on the control panel.
1. Remove paper from the left tray, then fold up the tray.
2. To open Door A, open Tray 5, then lift the release lever and open Door A.
WA
RNING: The area around the fuser can be hot. Use caution to avoid injury.
C
AUTION: Do not touch the transfer belt. Touching the belt can reduce image quality or
damage the transfer belt. Do not touch the transfer roller. Touching the roller can reduce
image quality.
3
1
2
