Xerox Phaser 3140 Service Manual

Phaser 3140/3155/3160 Printer Service Manual I – 1
Index
A
abbreviations, A-2
AC
input connection
, 1-6
requirements, 1-13
troubleshooting, 4-12
altitude adjustment, 6-2
B
background contamination, 5-14
banding, 5-22
black lines, 5-21
black prints, 5-11
blank prints, 5-28
button
definitions
, 1-7
location, 1-7
C
clearances, 1-15
Clutch Assembly
part number
, 9-17
clutch assembly
removal
, 8-37
consumable, 1-10
Print Cartridge, 1-10
Control Panel
buttons
, 1-7
description, 1-7
Error LED, 1-8
Online LED, 1-8
part number, 9-7
removal, 8-51
Controller Board, 2-11
3140 wiring, 10-15
3155 wiring, 10-19
3160 wiring, 10-23
connector definitions, 2-11
designators, 10-2
operation, 2-11
part number, 9-5
removal, 8-51
CRUM, 2-8
curl, 5-31
D
dimensions, 1-15
Drive Assembly, 2-6
operation, 2-6
part number
3140
, 9-21
3155/3160, 9-23
removal, 8-35
E
electrostatic discharge, 0-xii
Error LED
color codes
, 1-8
Ethernet
port location
, 1-6
Exit Actuator
Spring
part number
, 9-27
Exit Sensor, 2-17
Exit Sensor Actuator
location
, 2-17
F
Fan, 2-17
part number, 9-16
removal, 8-58
fasteners, 8-5
precautions, 8-5
Feed Actuator
part number
, 9-17
removal, 8-40
Spring
part number
, 9-17
Downloaded From ManualsPrinter.com Manuals

Xerox Phaser 3140 Specifications

General

Color	No
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	80 sheets
Maximum duty cycle	10000 pages per month
Page description languages	GDI
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Mac compatibility	Yes
Custom media sizes	76 x 127 - 216 x 356 mm
Compatible operating systems	Windows 2000/XP/2003, Vista, Mac OS
Power consumption (standby)	60 W
Power consumption (printing)	360 W
Display	-
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	360 x 389 x 230 mm
