Parts List
Phaser® 3500 Laser Printer Service Manual
5-12
5-4 SPRING EXIT ROLL FD
6 ROLLER EXIT F/DOWN 006N01264
7 HOLDER M BUSHING EXIT 013E25770
8 PMO ACTUATOR OUT FULL 120N00479
9 GEAR M EXIT Z17 007N01364
10 HOLDER BUSHING EXIT (F/DOWN) 013E25770
11 MEA UNIT ROLL EXIT DUPLEX 006N01265
11-1 SHAFT M EXIT DUPLEX
11-2 RMO RUBBER EXIT DUP
12 BUSH M EXIT D7 013N13839
13 GEAR M EXIT DUP Z21 007N01363
14 ELA HOU CST SENSOR 110K14290
14-1 PBA SUB CASSETTE
14-2 IPR PLATE SENSOR
14-3 IPR BRACKET SENSOR
15 CBF HARNESS PSIZE
16 GUIDE P REGI UPPER
17 SPRING ETC LEVER
18 HOLDER M BUSHING TX
19 GUIDE PLATE PAPER
20 IPR P GROUND PLATE PAPER
21 PHOTO INTERRUPTER 110K14300
23 CBF HARNESS THERM
24 PMO HOUSING TERMINAL
25 IPR TERMINAL FU
26 CBF HARNESS FUSER
27 CAP M HOUS TERM
28 SHIELD P CTRL
29 GROUND P MOTOR DEVE
30 GROUND P GUIDE TR
31 GROUND P REGI ROLLER
32 GROUND P PICK UP MP
Frame Assembly (Continued)
Item No. Description Qty Part Number
