Phaser® 3500 Laser Printer Service Manual
5-13
33 GROUND P SCF MAIN
34 GROUND P MOTOR MAIN
35 GROUND P GUIDE DUP
36 CAP M GUIDE HARNESS
37 PMO DUMMY DEVE
38 ELA HOU VARISTOR
39 FOOT ML80
40 PMO REMOVE LOCK CST
41 SHAFT M GEAR RETARD
42 SHAFT M COUPLING RETARD
43 PMO BEARING SHAFT
44 GEAR REGI Z25
45 PMO BEARING SHAFT
47 MEA UNIT FRAME LSU LOW 140N63017
47-1 FRAME M LSU LOWER
47-2 PBA TONER SENSOR
47-3 TERMINAL P DEVE
47-4 CBFHARNESS TONER SENSOR
47-5 CAP M COVER OPEN
48 ELA UNIT FEED 3X5 022N02174
48-1 HOLDER M SAW
48-2 GUIDE P TRANSFER FRONT
48-3 PLATE P SAW
48-4 SHAFT M ROLLER BELT
48-5 ROLLER M IDLE BELT
48-6 IEX SHAFT IDLE, F/UP
48-7 RUBBER BELT FEED
48-8 GUIDE M SHAFT BELT
49 ELA UNIT RETARD 022N02175
49-1 FRAME M RETARD
49-2 HOLDER M RETARD
49-3 SPRING ETC PAD
Frame Assembly (Continued)
Item No. Description Qty Part Number
