Parts List
Phaser® 3500 Laser Printer Service Manual
5-14
49-4 BUSH M RETARD 2
49-5 HOUSING M RETARD
49-6 SHAFT RETARD
49-7 RING-E
49-8 PMO HUB OUT RETARD
49-9 SPRING TS
49-10 PMO HUB IN RETARD
49-11 RUBBER RETARD
50 ELA UNIT FEED2 IDLE 022N02176
50-1 HOLDER IDLE FEED2
50-2 CAP M IDLE FEED2
50-3 SPRING ETC PAD
50-4 BUSH M RETARD
50-5 SHAFT IDLE FEED2
50-6 RING-E
50-7 ROLLER M IDLE FEED2
50-9 SHAFT HUB IN
51 STOPPER M KNOCK UP MP L
52 STOPPER M KNOCK UP MP R
53 RAIL M LEFT DUPLEX 032N00441
54 RAIL M RIGHT DUPLEX 032N00442
55 PMO BEARING SHAFT
56 GEAR REGI E25
57 BEARING PICK UP
58 PMO ACTUATOR EMPTY 120E26090
59 ELA UNIT PICK UP 022N02183
59-1 SHAFT PICK UP
59-2 MEA UNIT P/UP HOUSING (PICK ROLLER) 022N02177
59-2-1 PMO M IDLE PICK UP
59-2-3 RUBBER PICK UP
59-3 PMO M CAM PICKUP
59-4 SHAFT FEED 1
Frame Assembly (Continued)
Item No. Description Qty Part Number
