Parts List
Phaser® 3500 Laser Printer Service Manual
5-15
59-5 AS FEED 1 ROLL ASSY 022N02187
59-5-1 HOUSING M FEED1
59-5-2 RUBBER FEED1
59-6 GROUND P PICK UP MAIN
59-7 BEARING PICK UP
59-8 PMO BUSHING FEED
59-9 GUIDE P FRONT DUP PICKUP
59-10 GUIDE M SUPPORT PICKUP
60 ELA UNIT FEED2 022N02178
60-1 FRAME M PICK UP
60-2 PMO BUSHING FEED
60-3 SHAFT M FEED2
60-4 BEARING PICK UP
60-5 RUBBER ROLLER FEED2
61 PBA SUB JOINT 140N63022
62 CBF HARNESS TRAY OUT
63 CAP M POWER
64 CBF HARNESS INLET 152N11619
65 SHAFT M BELT GEAR
66 PMO BEARING SHAFT
67 GEAR M EXIT Z17
68 CAP M DEVE MOTOR
69 CBF HARNESS DUPLEX
71 CAP M WIRE PTL LOWER 021N02249
72 TERMINAL P PTL 116N00243
73 CBF HARNESS PTL
74 PBA SUB COVER OPEN 130N01399
76 PBA SUB EXIT SENSOR 130N01400
77 PBA FUSER SW 130N01401
78 GUIDE M FRONT
79 TERMINAL P GUIDE FRONT
Frame Assembly (Continued)
Item No. Description Qty Part Number
To Next Page
