Xerox PHASER 6130 Service Manual

Phaser 6130 Color Laser Printer Service Manual 8-5
Service Parts Disassembly
W
arn
i
ng
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
b. Fuser (page 8-9).
7. Open the Toner Access Door.
8. Remove the Toner Cartridges (page 8-10).
N
o
t
e
Names of parts that appear in the removal and replacement procedures
may not match the names that appear in the Parts List. For example, a
part called the Registration Chute Assembly in a removal procedure may
appear on the Parts List as Assembly, Registration Chute. When working
on a removal procedure, ignore any prerequisite procedure for parts
already removed.
Caution
Many parts are secured by plastic tabs. DO NOT over flex or force these
parts. DO NOT over torque the screws threaded into plastic parts.
W
arn
i
ng
Unplug the AC power cord from the wall outlet before removing any
printer part.
Notations in the Disassembly Text
■ The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
■ The notation “PLX.X.X” indicates that this component is listed in the Parts
List.
■ Bold arrows in an illustration show direction of movement when removing
or replacing a component.
■ The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Note
Provides information specific to the replacement of parts or
assemblies.

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
