Print-Quality Troubleshooting
Test Prints
This section provides information for how to analyze test prints. A variety of
test prints are available for determining the quality of output from the printer
and to assist in troubleshooting the problems.
■ No Image IOT
■ Pattern IOT
■ Grid 2 ESS
■ Cyan 20% ESS
■ Magenta 20% ESS
■ Yel lo w 2 0 % E S S
■ Black 20% ESS
■ CMY 20% ESS
■ Gradation ESS
No Image IOT
This test print provides a sample of blank
page. This test is used to identify
problems with the printer function.
■ Fail: Check the printer function.
■ Pass: Check the network
connection, cable, PC...etc.
