Sub Drive Assembly
Rotation power of the DRIVE ASSY SUB is transmitted through the route
below.
Full Color Mode
Gear D1
Gear D2
Gear DK
Gear D1
Sub Motor
Gear D5
Magnet Gear (K)
Sub Drive Imaging Unit Drive
Gear D3 In
Gear D3 Out
Developer
Housing (K)
[ Magnet Roll (K) ]
Magnet Gear (C)
[ Magnet Roll (C) ]
Magnet Gear (M)
Developer
Housing (M)
[ Magnet Roll (M) ]
Magnet Gear (Y)
Gear D5 Gear D5 Gear D5
Gear D4
Gear D4
Developer
Housing (Y)
[ Magnet Roll (Y) ]
Imaging Unit
s6130-034
[ Name Of Moving Parts ]
Full Color Mode
Developer
Housing (K)
