4-2 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
Introduction
This chapter covers the System Startup, Power On Self Test (POST), Service
Diagnostics, and troubleshooting problems that are not associated with a
Chain Link code or Control Panel error message.
For troubleshooting problems associated with a Chain Link code or Control
Panel error message, refer to “Error Messages and Codes” on page 3-1.
Print-quality problems are covered in “Print-Quality Troubleshooting” on
page 5-1.
System Startup
Listed here is a typical startup routine from a cold start. The printer requires
approximately 20 seconds to complete this sequence.
1. When the power switch is turned On, the “Health” LED on the Image
Processor Board turns On immediately.
2. The Boot Loader checks for RAM present and functional. If an error is
detected, RAM ERROR is displayed and the Health LEDs alternately blink
at 1/2 second intervals.
3. The Boot Loader then loads and runs POST diagnostics.
4. POST turns Off the Health LED.
5. POST checks the Control Panel.
6. The Control Panel LED cycles: Green and Red simultaneously, and
Green.
7. The Control Panel LED turns Green and Red and Diagnosing...
message is displayed.
8. The Control Panel message changes to Ready Calibrating and then
Xerox (TM) Toner Cartridge.
9. The Control Panel LED turns Green and the Ready message is
displayed.

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
