Phaser 6130 Color Laser Printer Service Manual 4-37
General Troubleshooting
Control Panel Troubleshooting
Printer Does Not Come to a “Ready” State
1. Reseat connectors on the Image Processor Board (page 8-60).
2. Refer to “DC Power Supply Troubleshooting” on page 4-41.
3. Replace the Control Panel (page 8-13).
4. Replace the Control Panel wiring harness (page 8-54).
Control Panel LED is On, Control Panel Display is Blank
1. Remove and reseat the Image Processor Board (page 8-60).
2. Replace the Control Panel (page 8-13).
3. Replace the Control Panel wiring harness (page 8-54).
4. Replace the Image Processor Board (page 8-60).
