Phaser 6130 Color Laser Printer Service Manual 5-45
Print-Quality Troubleshooting
Repeating Bands, Lines, Marks, or Spots
There are recurring lines, marks, or spots on the page.
Initial Actions
■ Check the paper transfer path.
■ Ensure there are no debris on the transfer path.
arn
ng
To prevent burns, allow the Fuser to cool down before starting the
procedure.
Troubleshooting Reference Table
Applicable Notes Example Print
■ Transfer Unit, PL4.1.1
■ Print Cartridge (C/M/Y/K),
PL5.1.18-21
■ Fuser, PL6.1.10
■ Laser Unit, PL5.1.2
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check for spot’s regular intervals. Do
spots, lines, or marks that might
appear on the page occur at regular
intervals?
Refer to
“Repeating
Defect
Measurement”
on page 5-21.
Complete.
ABCDE abcde 12345
s6180-488
To Next Page
