3-44 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
Jam at Exit
The Registration Sensor indicates that paper did not reach the sensor on time
or that paper remains in the Registration Chute.
arn
ng
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
Initial Actions
■ Ask the customer about the paper types being used. If not on the
recommended list, determine if this is contributing to the problem.
Recycled, multi-purpose or copier paper tends to contaminate the paper
path. Constant use of special papers such labels or business cards can
also contribute to jamming.
■ Ensure the correct tray loading and setup procedures are followed
(securing the guides, selecting the correct paper type, fanning the paper,
etc.)
■ Make sure the printer is plugged directly into an electrical outlet. Using
extension cords or a power strip is not recommended.
■ Make every attempt to establish a jam rate prior to starting any work. If
possible print an Error History Report and note the page count between
jams.
■ Determine if jamming is occurring in the tray but not the manual feed slot
or vice-versa. This helps to identify any dirty or defective parts.
■ Clear the paper path of any jams and paper debris. Start at the Turn
Chute and work up to the Registration Chute Assembly.
■ Clean the paper Feed and Separator Rollers in the paper tray and tray
slot using a slightly damp (water only) lint free cloth.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting References Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser Harness, PL6.1.2
■ Fuser, PL6.1.1
■ MCU Board, PL8.2.13
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Fuser” on page 10-29
To Next Page
