4-40 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
AC Power Supply Troubleshooting
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack References
■ LVPS, PL9.1.4 ■ “DC Power Supply” on page 10-17
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the voltage at the AC wall outlet. Is
there approximately 110 VAC (or 220 VAC if
the printer is a 220 V configuration) at the
AC wall outlet?
Go to step 2. Notify the
customer of
improper AC
output from
the outlet.
2 Check the power cord for defects or a loose
connection. Is the power cord loose or
defective?
Replace or
reconnect the
power cord.
Replace the
LVPS
(page 8-55).
To Next Page
