Phaser 6130 Color Laser Printer Service Manual 3-79
Error Messages and Codes
Download Mode
The MCU downloaded file is invalid.
Applicable Chain Link
■ 024-360: MCU Firmware Download Error
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL8.1.9
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the download firmware
Is the download firmware for the
6130N?
Go to step 2. Re-download
the correct
firmware.
2 Check the Image Processor Board
installation
Reseat all connectors on the Image
Processor Board.
Does the error still occur when
downloading the firmware?
Replace the
Processor Board
(page 8-60).
Complete
