Xerox PHASER 6130 - Parameter Setting

Phaser 6130 Color Laser Printer Service Manual 6-7
Adjustments and Calibrations
Parameter Setting
This function reads/writes the parameter values, errors, and life counter
values stored in the printer.
N
o
t
e
Print the parameter list from Service Mode > Parameter > Print before
changing the registration value. The parameter list contains the parameter
and life counter values currently stored in the engine.
To access the Parameter list:
1. Turn the printer power Off (if the printer is On).
2. Simultaneously press the Up Arrow and Down Arrow buttons and turn
on the printer.
3. The Service Mode menu is displayed.
4. Press the Up Arrow or Down Arrow button to find Parameter. Press the
OK button.
5. Select the appropriate item to change (i.e., Slow Scan KtoP). Press the
OK button.
6. Enter the appropriate range using the Up Arrow or Down Arrow button.
Press the OK button.
7. The new value “# *” is displayed.
N
o
t
e
“*” = data has been saved
8. Press the Cancel button to return to the Parameter menu.
Parameter Setting
Item
Range
Description
Slow Scan K to P -128 to 127 Sets the registration in the paper feeding
direction.
Slow Scan 600 Y/M/C -30 to 30
Fast Scan K to M, Y, C -128 to 127 Sets the registration in the scanning
direction.
Fast Scan 2 K to M, Y, C -1 to 2
Fast Scan M-Feed, Tray -30 to 30
Life Counter — Reads the life counter and the printer.
