Xerox PHASER 6130 Service Manual

3-2 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
Introduction
This chapter describes error messages and numeric codes displayed on the
Control Panel or listed on the Error History page. These error indications
serve as the entry point into the troubleshooting process.
Troubleshooting of problems not directly indicated by or associated with an
error message or Chain Link code is covered in “General Troubleshooting” on
page 4-1. Print quality problems are covered in “Print-Quality
Troubleshooting” on page 5-1.
The printer tracks and reports errors in a number of ways. The two types of
error reporting discussed in this section include:
■ Error messages and Chain Link codes display on the Control Panel
■ Engine (fatal) and Jam Error logs display on the Control Panel or listed on
the Error History Report
Accessing Error History Report
1. From the Control Panel, press the Menu button.
2. Information Pgs is displayed. Press the OK button.
3. Press the Up or Down arrow button to find Error History. Press the OK
button.
4. The Error History Report is printed. When printing is finished, the menu is
displayed.
Error History Report
The Error History Report provides a list of error messages and Chain Link
codes relating to Jam errors and System (fatal) errors. The printer can retain
up to 42 Jam errors and 42 System Fail errors.
For Chain Link codes, Chain number (0 to 999) and Link number (0 to 999)
are assigned. Chain numbers are assigned for each component. The
component number that detects the Fault is entered in the Chain code, and
the Fault type is defined by the Link code.
Examples of Error message and Chain Link code:
■ System Fail History
■ Chain Link: 018-310
■ Paper Jam History
■ Paper Jam Type: IOT Remain Registration Jam

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
