Xerox PHASER 6130 - Replace Fuser; Fuser Life

Phaser 6130 Color Laser Printer Service Manual 3-63
Error Messages and Codes
Replace Fuser / Fuser Life
The Fuser has reached end of life.
Applicable Chain Link
■ 010-351: The Fuser is at end of life.
5 Check the resistances of Temp. Sensor
in the Fuser
Remove the Fuser.
Warning: Start the operation after the
Fuser has cooled down.
Check the resistances across the
following pins of the removed Fuser.
J171-5 <=> J171-4
J171-6 <=> J171-8
J171-6 <=> J171-7
Can the resistances be measured?
(The resistances are 7 k-ohm at 180
degrees C).
Replace the
MCU Board
(page 8-59)
Replace the
Fuser
(page 8-9).
After replacing
the Fuser, be
sure to reset the
life counter
value.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Fuser (PL6.1.1)
MCU Board (PL8.2.13)
■ “Map 2 - Laser Unit, Feeder Assembly”
on page 10-9
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Feeder, Manual Feed, & Registration” on
page 10-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the life counter value of the
Fuser
Does the life counter value show the
near of the end?
Replace the
Fuser
(page 8-9).
After replacing
the Fuser, be
sure to reset the
life counter
value.
Go to step 2.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
