General Troubleshooting
Power On Self Test (POST)
POST Diagnostics provide a quick mean of isolating a defective subsystem
associated with the Image Processor Board and SDRAM. POST returns
control to the boot loader and the operating system is loaded.
The following tests are performed when the printer is powered On.
1. Checks and initializes CRU Register.
2. Initializes ASIC.
3. Checks RAM.
4. Initializes the Control Panel driver.
5. Processes the ROM Sum Check.
6. Initializes Memory Manager.
7. Initializes EEPROM driver.
8. Initializes IOT Controller.
9. Starts the Operating System process.
10. Printer is Ready.
POST Test Description
Test Chain Link Description
CodeROM 116-317 This test calculates the ROM checksum chip by
chip and compares it with the value stored in the
CodeROM itself.
Checksum error is in the main program ROM.
FontROM This test calculates the FontROM checksum chip
by chip and compares it with the value stored in
the FontROM itself.
116-310 Checksum error is in the built-in FontROM.
116-317 Checksum error is in the main program ROM.
EEPROM This test writes/reads/verifies on the diagnostic
area of the EEPROM.
116-323 Error is detected in EEPROM0 during
initialization.
116-326 Error is detected in EEPROM1 during
initialization.
DRAM This test checks OPEN/SHORT of the address
line of the DRAM. This test also writes/reads/
verifies on the entire DRAM.
116-315 Error is detected if included RAM is different.
116-316 Error is detected if extended RAM is different.
116-320 Error is detected if extended RAM is not
supported.
MAC+PHY Test 116-352 This test performs PHY internal loopback.
ASIC 116-343 Performs register test.

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
