3-50 Phaser 6130 Color Laser Printer Service Manual
Error Messages and Codes
MPC Errors
MPC Error
Multi-Protocol Network Card error occurs.
Applicable Chain Link
■ 016-738: MPC Error (Download Initial Error)
■ 016-739: MPC Error (Reseat MPC)
■ 016-740: MPC Communication Error
■ 018-310: MPC Error (NIC Controller Communication)
■ 018-311: MPC Error (NIC Flash ROM Boot Module Checksum Error)
■ 018-312: MPC Error (......)
■ 018-313: MPC Error (NIC Flash ROM Application Module Checksum
Error)
■ 018-314: MPC Error (NIC MAC Address Checksum Error)
■ 018-315: MPC Error (NIC Ethernet BIST Parity/RAM R/W Error)
■ 018-316: MPC Error (NIC Internal Loopback Error)
■ 018-317: MPC Error (NIC Fatal Error)
■ 116-333: MPC Error (PCI Option #0 Failure)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Multi-Protocol Network Card
(Option), PL8.1.11
■ Image Processor Board, PL8.1.9
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Multi-Protocol Network
Card (MPC) for correct installation. Is
the MPC correctly installed?
Go to step 2. Reseat the
MPC. Go to step
2.
2 Does the error still occur? Go to step 3. Complete.
3 Replace the Multi-Protocol Network
Card (page 8-62).
Replace the
Processor Board
(page 8-60).
Complete.
