Xerox PHASER 6130 Service Manual

4-46 Phaser 6130 Color Laser Printer Service Manual
General Troubleshooting
Abnormal Noise During Printing
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Separator Roller Assembly (PL2.1.5)
■ Feed Roller Assembly (PL3.2.4)
■ Imaging Unit (PL4.1.21)
■ Fuser (PL6.1.1)
■ Transfer Unit (PL6.1.7)
■ Sub Drive Assembly (PL7.1.1)
■ Main Drive Assembly (PL7.1.2)
■ Fan (PL8.1.1)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the noise present when paper is fed from
the Tray?
Go to step 2. Go to step 6.
2 Check the paper condition in the Tray
Is the paper dry and approved paper?
Go to step 4. Replace with
dry and
approved
paper, then
go to step 3.
3 Check noise when the paper is fed from the
Tray 1
Is the noise still present?
Go to step 4. Complete
4 1. Remove the Paper Tray from the printer.
2.Rotate the Separator Roller in the Paper
Tray with your finger.
Does the Separator Roller rotate smoothly?
Go to step 5. Replace the
Separator
Roller
Assembly
(page 8-7).
5 Check the Feed Roller Assembly for rotation
1.Remove the Paper Tray from the printer.
2.Start the Main Motor FULL2 test
(page 4-27): Service Mode > Engine
Diag > Motor Test > Main Motor FULL2,
then while the motor is running, start the
Tray Feed Solenoid (Auto) test
(page 4-34): Service Mode > Engine
Diag > Motor Test > Tray Feed Solenoid
(Auto).
Is the noise coming from this Roller?
NOTE: After check is completed, turn off the
Tray Feed Solenoid test first, then turn off
the Main Motor FULL2 test.
Replace the
Feed Roller
Assembly
(page 8-30).
Go to step 9.

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
