Xerox PHASER 6130 Service Manual

9-26 Phaser 6130 Color Laser Printer Service Manual
Parts List
Service Kits
Service Kits are developed to provide an easy means to obtain spare parts
normally associated with larger assemblies. A number of Service Kits have
been developed for the Phaser 6130. The following tables list the contents for
each kit.
Kits
Power Cords
Description
Part Number
Power Cord, North America (NEMA 5-15), 125 V, 13A 117E35170
Power Cord, Italy, 230 V 117E29450
Power Cord, Denmark, 230 V 117E29460
Power Cord, India/South Africa, 230 V 117E29470
Power Cord, Israel, 230 V 117E29480
Power Cord, Australia, 230 V 117E29490
Power Cord, Euro, 230 V 117E29500
Power Cord, UK, 240 V 117E29510
Power Cord, China, 220 V 117E35030
Power Cord, Argentina, 220 V 117E35040
Power Cord, Switzerland, 230 V 117E35050
Hardware Kit
Parts List Reference Description
Part Number
99.99.99 Hardware Kit 604K34030
Screw, Bind Head Del (1)
Screw, 8 mm Plastic (1)
Screw, Tap Bind Head (1)
Screw, M3x6 B (1)
Screw, DT3x8 B (1)
E-Ring, 3 mm (1)
E-Ring, 4 mm (1)
Packaging Kit
Parts List Reference Description
Part Number
— Packaging Kit, PDL 110V
Packaging Kit, PDL 220V
100S64594
100S64595
— Packaging Kit, PDL DMO 110V
Packaging Kit, PDL DMO 220V
100S64644
100S64645

Xerox PHASER 6130 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Warm-up time (from sleep mode)	25 s
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Maximum internal memory	1152 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	251 sheets
Media weight (tray 1)	64 - 220 gsm
Multi-Purpose Tray media weight	64 - 164 g/m²
Functions	Print
I/O ports	10/100BaseTX Ethernet, USB 2.0
Device manager	Auto IP, BOOTP/RARP, DHCP, PrintingScout Alert Notification, SNMP v.2, Xerox CentreWare Internet Services Embedded Web Server, Email alerts
Package length	558.79 mm
Depth (imperial)	17.5 \
Width (imperial)	15.75 \
Height (imperial)	15.3 \
Security features	Secure Print
Power requirements	220–240 VAC, 50/60 Hz
Networking features	10/100 Base-TX Ethernet
Color space standard	ICM, ICC, PANTONE Color Approved
Enhanced scan resolution	600 x 600 DPI
Storage temperature (T-T)	32 - 95 °F
Power consumption (active)	280 W
Compatible operating systems	Windows 2000/2003 Server/XP/XP Home Edition (SP1 +)/ Vista, Mac OSX 10.2 +, Linux: SUSE 9.2 +/Turbo Linux 10/ Red Hat ES3 +/Fedora Core/Yellow Dog 3.X
Acoustic power emissions (standby)	43 dB
Non-operating relative humidity (non-condensing)	15 - 85 %
Acoustic power emissions (active, print, copy or scan)	64.6 dB
PCL fonts	81
Printer fonts	PCL, PostScript
Country of origin	China
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Number of PostScript fonts	136
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Operating temperature (T-T)	5 - 32 °C
Operating relative humidity (H-H)	15 - 80 %
Certification	FCC 15 B, UL 60950-1/CSA 60950-1-03, CE Mark 73/23/EEC, 89/336, EEC, Section 508 ADA
Package width	533.39 mm
Package height	507.99 mm
Package weight	22226.4 g

Weight and Dimensions

Depth	445 mm
Width	400 mm
Height	389 mm
Dimensions (WxDxH)	400 x 394 x 389 mm
