08/2012
6-13
WorkCentre 5021/5019
6.1.13, 6.1.14
General Procedures
Initial Issue
6.1.13 Warm-up Time
Machine requires the following warm-up time after prower is turned on, after exiting Low Power
Mode or Sleep Mode. Measuring Conditions:
• 20degC / 65%RH / Rated Voltage
• Not includeing toner recovery or set-up cycle.
• Power on after 3 hours or more seasoning with the power turned off.
• Machine configuration: Standard M/C
1. Time To Start Printing *1
2. Time to display Ready to Copy (reference)
*1: Time from Power On to 1st sheet output - Time from Standby to 1st sheet output.
The time A minus B below;
A: Time from when the power is tunred on and print is designated to when the trail edge of the
1st sheet is ejected from Exit.
B: Time from when the print is designated while IOT is in standby state to when the trail edge of
the 1st sheet is efected from Exit.
*2: When machine exits Sleep Mode / Low Power Mode after one hour passes from the transi-
tion to Sleep Mode / Low Power Mode.
6.1.14 FCOT :First Copy Output Time (Warm start)
FCOT shall be 7.5sec or less.
FCOT (Warm start) is from the time Start button is pressed (when the engine receives a START
command in the 'STAND-BY' state) till the trail edge of the first sheet is fed out in the following
conditions.
• Documents are placed on Platen
• Power is on
• Engine motor is not running
• Fusing Unit is ready
• Laser scanner motor (ROS: Raster Output Scanner) is ready
• Paper size and feeding orientation: A4 or 8.5x11 LEF
• Paper tray: Tray 1
• FCOT Mode
Table 1
Config After Power On
After ExitingSleep
Mode *2
After ExitingLow
Power Mode *2
220V M/C 30sec 30sec 30sec
120V M/C 30sec 30sec 30sec
Table 2
Config After Power On
After ExitingSleep
Mode *2
After ExitingLow
Power Mode *2
220V M/C 30sec 30sec 30sec
120V M/C 30sec 30sec 30sec
