08/2012
6-14
WorkCentre 5021/5019
6.1.15, 6.1.16
Initial Issue
General Procedures
6.1.15 Print Speed
Continuous speed (PPM) of the print engine is defined as follows:
During output to Face Down Tray, taking the time from when the tail edge of the 1st sheet is
output from the IOT exit area until the tail edge of the 11th sheet is output from the MC exit
area to be t seconds, the no. of sheets that is printed in 1 minute is given by the formula: [(60/
t)x10 for 1 Sided and (60/t)x20 for 2 Sided] as shown in the following table. The numerical
value for Duplex is IPM (Images Per Minute).
Limitations
• This does not include the time for settings/cleaning/sagging/procon.
• When automatic recognition of paper size at the MSI is in operation, it prints at the corre-
sponding productivity rate of that paper size. However, if the paper size is not automati-
cally detected, the 1st paper is printed with the same productivity as the A3 SEF or 17’
paper. Immediately after that, the 2nd BTR is cleaned, then the 2nd and subsequent
paper will be printed with the productivity of the paper size that was detected when print-
ing the 1st paper.
20/18 IOT (feed from Tray/output to Center Tray)
Unit: 1 Sided: ppm, 2 Sided: ipm
*: There is no 2 Sided for Plain Reload
6.1.16 Tray (Paper Feed)
6.1.16.1 Paper Trays
Paper Trays refer to all type of Trays that are pulled out towards the front. The Main Unit has
the MSI and the 250-sheet Paper Tray (1 level) as standard configuration.The 500-sheet Paper
Tray (Single Tray Module: STM) is available as a field option.The MSI is installed on the left
side of the IOT by standard.
6.1.16.2 Paper Tray Characteristics
*1: B Zone/Fresh Paper, P Paper
6.1.16.3 Remaining Paper Amount Detection
• When the power is turned OFF during liftup, if the power is turned ON again without
removing the Tray, and the Tray is inserted again while the Bottom Plate has not dropped,
the remaining paper amount cannot be detected correctly.
Table 1
Paper
Type
Settings
216.0 mm or
shorter in the
SS direction
and 210.0
mm or longer
in the FS
direction
216.1 mm to
297.2 mm in
the SS
direction
297.3 mm to
364.1 mm in
the SS
direction
364.2 mm to
432.0 mm in the
SS direction
(A3S/11x17S)
A4 LEF
8.5x11 LEF
B5 LEF
A5 SEF
B5 SEF
5.5x8.5 SEF
A4 SEF
8.5x11 SEF
B4 SEF
8.5x13
SEF8.5x14
SEF8.5x13.4
SEF
A3 SEF
11x17 SEF
1
Sided
2
Sided
1
Sided
2
Sided
1
Sided
2
Sided
1
Sided
2
Sided 1 Sided 2 Sided
Bond-
PlainRe-
cycledPla
in Reload
*
20/18 13.1/
13.1
12/12 7.2/
7.2
15/14 8.7/
8.7
12/12 7.9/7.9 10/10 7.2/7.2
Table 1
IOT/
TM
Tray
NO.
Supported Paper
(Standard Size)
Supported
Paper
(Non-Standard
Size) (W x L)
mm
Supporte
d Paper
Weight
(gsm)
Storage
Capacity
*1 Remarks
IOT Tray1 Min:B5
Max:A3S,11X17S
Non-Standard
Sizes not sup-
ported
60-90 250sheets
(Business
80gsm)
Stack height: 27
mm
MSI Min:A5S, 5.5X8.5
Max:A3S,11X17S
Non-Standard
Sizes not sup-
ported
60-110 100sheets
(Business
70gsm)
Stack height: 10
mm
STM Tray2 Min:B5S
Max:A3S,11X17S
Non-Standard
Sizes not sup-
ported
60-90 500sheets
(Business
70gsm)
450sheets
(Business
80gsm)
Stack height: 54
mm
Table 2
Tray Detection & Notification Remarks
Tray1-2 1 level: 0%
MSI 1 level: 0%
