Xerox WorkCentre 5021 Service Documentation

08/2012
6-53
WorkCentre 5021/5019
6.3.9
General Procedures
Initial Issue
6.3.9 NVM PH
Table 1 NVM PH
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Yes/No
Initialization
Yes/No Description
742-001 PH_LEAD_REGI_ALL_TRAY -50 50 0 Enable Enable LEAD REGI ADJUSTMENT - ALL TRAY
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-002 PH_LEAD_REGI_TRAY1 -50 50 0 Enable Enable TRAY1 for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-003 PH_LEAD_REGI_TRAY2 -50 50 0 Enable Enable TRAY2 for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-004 PH_LEAD_REGI_MSI -50 50 0 Enable Enable MSI for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-005 PH_LEAD_REGI_DUPLEX -50 50 0 Enable Enable DUP ALL SIZE for Normal LEAD REGI ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-006 PH_REGI_LOOP_ALL_TRAY -50 50 0 Enable Enable REGI LOOP ADJUSTMENT - ALL TRAY
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-007 PH_REGI_LOOP_TRAY1 -50 50 0 Enable Enable TRAY1 for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-008 PH_REGI_LOOP_TRAY2 -50 50 0 Enable Enable TRAY2 for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-009 PH_REGI_LOOP_MSI -50 50 0 Enable Enable MSI for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-010 PH_REGI_LOOP_DUPLEX -50 50 -10 Enable Enable DUP ALL SIZE for Normal REGI LOOP ADJ
Image input is delayed when Set Value is increased.
(Unit: 2 ms)
742-040 PH_DUP_OPT_ENABLE_SWITCH 0 1 0 Enable Enable Dup Option Availability Switch
0: No Dup Option
1: Dup Option available
742-041 PH_ROS_LASER_SIDE_REGI_ADJUSTMENT_
ALL_TRAY
-50 1 0 Enable Enable ROS Write Position (All)
(0.169 mm increments)
742-042 PH_ROS_LASER_SIDE_REGI_ADJUSTMENT_
TRAY1
-50 50 0 Enable Enable ROS Write Position (Tray 1)
(0.169 mm increments)
742-043 PH_ROS_LASER_SIDE_REGI_ADJUSTMENT_
TRAY2
-49 49 0 Enable Enable ROS Write Position (Tray 2)
(0.169 mm increments)
