Xerox WorkCentre 5022 - Page 211

Too ls
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
9-25
6. Select the speed dial number to register to the group.
7. Press the button.
Notes
- A checkmark appears in the checkbox next to each Speed Dial entry. Pressing the button
again erases the checkmark .
- If you press the # button, you can check the details for the selected Speed Dial entry. Press
the Back button to return the display to the previous screen.
- You can select up to 99 Speed Dial entries at once.
8. Repeat Steps 6 and 7 to select the speed dial numbers to register to the group, and then press the
OK button.
9. Select Apply Settings, and then press the OK button.
10. Select Yes, and then press the OK button.
button
Speed Dial Number ... 002,010
Group 01 [C]:Delete
Name
... Group01
Apply Settings ...
No
Apply Settings [Are You Sure?]
Yes
