Maintenance
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
12-7
Replacing the Drum Cartridge
The following error codes and icons display in the machine status diagram when the drum cartridge is
near the end of its service life.
Call the Customer Support Center to order a replacement drum cartridge.
*The remaining page yield for copy/print jobs is applicable when A4 paper LEF ( ) is used. Actual
remaining service life will vary depending on the paper size and orientation, number of consecutive
pages printed, and the machine's operating environment. Use the figures above only as a guideline.
Notes
• The use of drum cartridges not recommended by Xerox may degrade image quality and
performance. Use only drum cartridges recommended by Xerox.
• Do not expose drum cartridges to direct sunlight or strong light from indoor fluorescent lighting.
Do not touch or scratch the surface of the drum. Doing so may result in unsatisfactory print
quality.
Error Code Message Required Action
091-440 Drum Near End of Life
Drum cartridge is near end of life.
Reorder a drum cartridge.
The drum cartridge will need to be replaced
after the following number of pages. Have
a replacement drum cartridge ready.
WorkCentre 5024: Approx. 4,000 pages
WorkCentre 5022: Approx. 3,000 pages
091-402
091-441
Drum Near End of Life
Drum cartridge is near end of life.
Replace drum cartridge soon.
The drum cartridge will need to be replaced
after about 1,000 pages*. Have a
replacement drum cartridge ready.
091-430 Drum End of Life
Replace drum cartridge.
The error icon is lit. The drum cartridge
needs to be replaced. Replace the drum
cartridge.
091-401 Drum Near End of Life
Image quality problem may occur.
Replacement of drum cartridge is
recommended.
The error icon is lit. It is time of expiration
for the warranty period of the image
quality on the drum cartridge.
091-406 Drum end of Life
Machine problem may occur.
Replace drum cartridge.
The error icon is lit. It is time of expiration
for the warranty period of performance on
the drum cartridge.
091-424 Drum End of Life
Machine problem will occur soon.
Replace drum cartridge
immediately.
The error icon is lit. The machine detected
a failure due to the use of a dram cartridge
that is not supported.
Replace the drum cartridge immediately.
To Next Page
