Xerox WorkCentre 5022 User Manual

Problem Solving
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
13-47
Error
Code
Message
Area to Check/
Check Procedure
See Page:
071-105 Paper Jam in Tray 1
Check Tray 1.
Open Cover A and remove paper.
1. Left cover A
2. Tray 1
P. 13-49
P. 13-53
072-102 Paper Jam in Tray 2
Check Tray 2.
Open Cover B and remove paper.
1. One tray module cover B
2. Tray 2
P. 13-51
P. 13-53
072-105 Paper Jam at Cover B
Open Cover B and remove paper.
One tray module cover B P. 13-51
073-102 Paper Jam in Tray 3
Check Tray 3.
Open Cover C and remove paper.
1. Two tray module cover C
2. Tray 3
P. 13-52
P. 13-53
073-104 Paper Jam at Covers B and C
Open Cover B and Cover C, and remove
paper.
1. One tray module cover B
2. Two tray module cover C
P. 13-51
P. 13-52
073-105 Paper Jam at Cover B
Open Cover B and remove paper.
One tray module cover B P. 13-51
074-101
074-102
Paper Jam in Tray 4
Check Tray 4.
Open Cover C and remove paper.
1. Two tray module cover C
2. Tray 4
P. 13-52
P. 13-53
074-104 Paper Jam at Covers B and C
Open Cover B and Cover C, and remove
paper.
1. One tray module cover B
2. Two tray module cover C
P. 13-51
P. 13-52
074-105 Paper Jam at Cover B
Open Cover B and remove paper.
One tray module cover B P. 13-51
075-135 Paper Jam in Tray 5
Remove paper from Tray 5 and remove
paper.
1. Left cover A
2. Tray 5
P. 13-49
P. 13-54

Xerox WorkCentre 5022 Specifications

General

Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Duplex Printing	Manual
Paper Sizes	A3, A4, A5, B4, B5
Memory (Standard)	128 MB
Print Technology	Laser
Print Speed	Up to 22 ppm
Print Resolution	600 x 600 dpi
Copy Speed	Up to 22 cpm
Operating System Compatibility	Windows, Mac
First Page Out Time (Copy)	8 seconds
