Xilinx Virtex-5 RocketIO GTP User Manual

218 www.xilinx.com Virtex-5 RocketIO GTP Transceiver User Guide
UG196 (v1.3) May 25, 2007
Chapter 10: GTP-to-Board Interface
R
Table 10-8: SelectIO Adjacent to Analog Supplies (FF1136 Packages)
GTP_DUAL 1 mm 1.4 mm
MGT124
(1)
E7 E8, E6
MGT120 F5 E6, G5
MGT116 J5 H5, L4
MGT112 P5
MGT114 AA5 AB5, AC4
MGT118 AG5 AF5, AH5
MGT122 AK6 AH5, AJ6
MGT126
(1)
AK8 AK7, AK9, AM10
Notes:
1. GTP_DUAL only available on XC5LX110T devices.
Table 10-9: SelectIO Adjacent to MGTCLK (FF1136 Packages)
GTP_DUAL 1 mm 1.4 mm
124_REFCLK
(1)
E8 E7, E9
120_REFCLK F5
116_REFCLK H5 G5, J5
112_REFCLK P5 N5
114_REFCLK AA5
118_REFCLK AF5 AG5
122_REFCLK AK6
126_REFCLK
(1)
AK7 AK6, AK8
Notes:
1. GTP_DUAL only available on XC5LX110T devices.
