Xilinx Virtex-5 RocketIO GTP User Manual

Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 219
UG196 (v1.3) May 25, 2007
SelectIO-to-GTP Crosstalk Guidelines
R
Table 10-10: SelectIO Adjacent to Analog Supplies (FF1738 Packages)
GTP_DUAL 1 mm 1.4 mm
MGT132
(1)
E15 E14, D13
MGT128
(1)
E9 E10, E8, D7
MGT124 E5
MGT120 F5, H5
MGT116 N5 P5, R4
MGT112 W5 V5
MGT114 AE5 AD5, AF5, AG4
MGT118 AL5 AK5, AN4
MGT122 AT5, AV5
MGT126 AV5 AV6
MGT130
(1)
AV10 AV9, AV11, AW12
MGT134
(1)
AV16 AV15, AW18
Notes:
1. GTP_DUAL only available on XC5LX330T devices.
Table 10-11: SelectIO Adjacent to MGTCLK (FF1738 Packages)
GTP_DUAL 1 mm 1.4 mm
132_REFCLK
(1)
E17, E15
128_REFCLK
(1)
E10 E9
124_REFCLK
120_REFCLK F5 E5
116_REFCLK L5, N5
112_REFCLK V5 W5
114_REFCLK AD5 AC5, AE5
118_REFCLK AK5 AJ5, AL5
122_REFCLK AT5 AR5
126_REFCLK AV5
130_REFCLK
(1)
AV9 AV8 , AV10
134_REFCLK
(1)
AV15 AV14, AV16
Notes:
1. GTP_DUAL only available on XC5LX330T devices.
