Chapter 4: Implementation
R
Figure 4-7: XC5VLX110T-FF1738, XC5VLX220T-FF1738, and XC5VLX330T-FF1738 GTP Placement (3 of 3)
XC5VLX110T: GTP_DUAL_X0Y0
XC5VLX220T: GTP_DUAL_X0Y0
XC5VLX330T: GTP_DUAL_X0Y2
Power PinsRight Edge of the Die
XC5VLX110T: GTP_DUAL_X0Y1
XC5VLX220T: GTP_DUAL_X0Y1
XC5VLX330T: GTP_DUAL_X0Y3
XC5VLX110T: Not Available
XC5VLX220T: Not Available
XC5VLX330T: GTP_DUAL_X0Y1
XC5VLX110T: Not Available
XC5VLX220T: Not Available
XC5VLX330T: GTP_DUAL_X0Y0
AY11 MGTAVCCPLL_130AW9 MGTREFCLKP_130
AY9 MGTREFCLKN_130
AY10 MGTAVCC_130
AW10 MGTAVCC_130
BB11 MGTRXP1_130
BB10 MGTRXN1_130
AY8 MGTAVTTRX_130BB8 MGTRXP0_130
BB9 MGTRXN0_130
AY12 MGTAVTTTX_130
AY7 MGTAVTTTX_130
BA12 MGTTXP1_130
BA11 MGTTXN1_130
BA7 MGTTXP0_130
BA8 MGTTXN0_130
AY17 MGTAVCCPLL_134A
W15 MGTREFCLKP_134
AY15 MGTREFCLKN_134
AY16 MGTAVCC_134
AW16 MGTAVCC_134
BB17 MGTRXP1_134
BB16 MGTRXN1_134
AY14 MGTAVTTRX_134BB14 MGTRXP0_134
BB15 MGTRXN0_134
AY13 MGTAVTTTX_134
AY18 MGTAVTTTX_134
BA18 MGTTXP1_134
BA17 MGTTXN1_134
BA13 MGTTXP0_134
BA14 MGTTXN0_134
AV3MGTAVCCPLL_122AT4 MGTREFCLKP_122
AT3 MGTREFCLKN_122
AU3 MGTAVCC_122
AU4 MGTAVCC_122
AV1 MGTRXP1_122
AU1 MGTRXN1_122
AR3 MGTAVTTRX_122AR1 MGTRXP0_122
AT1 MGTRXN0_122
AP3 MGTAVTTTX_122
AW3MGTAVTTTX_122
AW2 MGTTXP1_122
AV2 MGTTXN1_122
AP2 MGTTXP0_122
AR2 MGTTXN0_122
AY5 MGTAVCCPLL_126AW4 MGTREFCLKP_126
AY4 MGTREFCLKN_126
AW5MGTAVCC_126
AY3 MGTA
VCC_126
BB5 MGTRXP1_126
BB4 MGTRXN1_126
AY2 MGTAVTTRX_126BB2 MGTRXP0_126
BB3 MGTRXN0_126
AY1 MGTAVTTTX_126
AY6 MGTAVTTTX_126
BA6 MGTTXP1_126
BA5 MGTTXN1_126
BA1 MGTTXP0_126
BA2 MGTTXN0_126
UG196_c4_07_110906
